SWIT FLOW6500 SDI & HDMI Wireless Video & Audio Transmission System
$4,549.00
In Stock
- Up to 6500' Line-of-Sight Range
- 1 x Transmitter & 1 x Receiver
- Transmits up to 1080p60 Video
- Uncompressed HDMI & 3G/HD/SD-SDI
Tracked ShippingRates shown at checkout
60-Day ReturnsOn eligible items
Expert SupportReal people, real advice
SWIT FLOW6500 SDI & HDMI Wireless Video & Audio Transmission System
The SWIT FLOW6500 SDI & HDMI Wireless Video & Audio Transmission System is a dependable addition to a serious kit.
Highlights
- Up to 6500' Line-of-Sight Range
- 1 x Transmitter & 1 x Receiver
- Transmits up to 1080p60 Video
- Uncompressed HDMI & 3G/HD/SD-SDI
Ordered from NIXTRONIC, it ships with full tracking worldwide and is backed by our 60-day returns on eligible items.
In the Box
- SWIT FLOW6500 SDI & HDMI Wireless Video & Audio Transmission System
- Transmitter
- Receiver
- 2 x Antenna
- Locking D-Tap to Barrel Cable (2')
- Power Adapter
- Articulating Arm
| SKU | FLOW6500 |
|---|---|
| Brand | SWIT |
| Antenna I/O | Transmitter: 2x RP-SMA |
|---|---|
| Video I/O | Transmitter: 1x BNC (3G-SDI) Input Transmitter: 1x BNC (3G-SDI) Loop Output Transmitter: 1x HDMI 1.3 Input |
| Embedded Audio | SDIHDMI |
| Audio I/O | No |
| Power I/O | Transmitter/Receiver: 1x Barrel Input |
| Other I/O | Transmitter/Receiver: 1x USB-B Input |
| Encryption | Yes: 128-Bit AES |
| Wireless | Wi-Fi 5 (802.11ac) |
|---|---|
| Wireless Range | 6561.7' / 2000 m |
| # of Channels | 7 |
| Frequency Range | 5180 to 5822.5 MHz |
| Mobile App Compatible | No |
| Cellular Support | No |
| Video Format | HDMI/SDI1080p: 60/59.94/50/30/29.97/25/24/23.98 1080 PsF: 24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
|---|---|
| Audio Format | Not Specified by Manufacturer |
| Timecode Support | No |
| Input Power | 7 to 34 VDC |
|---|---|
| Battery | Transmitter/Receiver: 1x L-Series Mount on Fixed Plate |
| Power Consumption | Transmitter/Receiver: 9 W |
| Tripod/Accessory Mounting | Receiver, Bottom1x 1/4"-20 Female |
|---|
| Status Display | On Transmitter Only |
|---|---|
| Environmental Resistance | No |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| Material of Construction | Metal |
| Dimensions | Transmitter: 4.2 x 2.6 x 1" / 106.5 x 66 x 24.7 mm Receiver: 7.5 x 7.5 x 1.8" / 190 x 190 x 46 mm |
| Weight | Transmitter: 10.09 oz / 286.00 g, Including Antenna Receiver: 3.3 lb / 1.5 kg |
| Package Weight | 14.855 lb |
|---|---|
| Box Dimensions (Lx WxH) | 20.5 x 16 x 6.3" |
